CHAUVET DJ

Gobo Zoom 2

$309.99

Thrill event guests with customized logos, icons and other designs with Gobo Zoom 2, a high-powered custom gobo projector with a punchy 70 W LED. Proper positioning of gobos is easy with an innovative manual rotation knob that allows fast indexing without gobo removal. Gobo Zoom 2 comes with 10 popular holiday gobos and manual zoom for short-throw or long-throw applications, making it versatile and convenient. The convenience doesn’t stop there. Most functions are accessible with an optional IRC-6 remote and set-up time can be reduced by power linking multiple units.

Product ships direct from Chauvet and is subject to inventory. If your product is out of stock you will be contacted.

SKU: GOBOZOOM2 Category: Tags: , , , ,

All fixture orders are shipped from Chauvet FL, customgobo.com and Contemporary Lights are not responsible for the order after it is picked up by the shipping company. Customgobo.com or Contemporary Lights are not responsible for delays due to Act of God, weather, incomplete or inaccurate address supplied by customer.

AT A GLANCE

  • High-powered custom gobo projector with a punchy 70 W LED
  • Innovative manual rotation knob allows fast indexing without gobo removal
  • Manual zoom for short-throw or long-throw applications
  • Includes 10 popular holiday gobos
  • Access most functions via the optional IRC-6 remote
  • Reduce set-up time by power linking multiple units
  • Fits best in the CHS-40 VIP gear bag
  • Includes 10 popular holiday gobos

Specifications

  • DMX Channels:1
  • DMX Connectors:3-pin XLR
  • Light Source:1 LED (cool white) 70 W, (3A), 50,000 hours life expectancy
  • PWM Frequency:4000 Hz
  • Illuminance:(21°): 8,030 lux @ 2 m
    (38°): 2,660 lux @ 2 m
  • Lumens: 2,894
  • Power Linking:7 units @ 120 V; 14 units @ 230 V
  • Input Voltage:100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current:74 W, 1 A @ 120 V, 60 Hz
    72 W, 0.6 A @ 230 V, 50 Hz
  • Weight:5.8 lb (2.6 kg)
  • Size:13 x 6 x 5.7 in (330 x 150 x 145 mm)
  • Approvals:CE
  • Gobo Size (E): 37.3 mm outside, 22 mm image, 1 mm max thickness
  • Zoom Angle (manual): 21° to 38°
  • Bracket Mounting Hole: 13 mm
  • Optional Controllers: IRC

WHAT'S INCLUDED

  • Gobo Zoom 2
  • Power cord
  • Quick Reference Guide
